Background:
Automatic landmarking software packages simplify the analysis of the 3D facial images. Their main deficiency is the limited accuracy of detecting landmarks for routine clinical applications. Cliniface is readily available open-access software for automatic facial landmarking, its validity has not been fully investigated.

Objectives:
Evaluate the accuracy of Cliniface software in comparison with the developed patch-based Convoluted Neural Network (CNN) algorithm in identifying facial landmarks.

Materials /Methods:
The study was carried out on 30 3D photographic images; twenty anatomical facial landmarks were used for the analysis. The manual digitization of the landmarks was repeated twice by an expert operator, which considered the ground truth for the analysis. Each 3D facial image was imported into Cliniface software, and the landmarks were detected automatically. The same set of the facial landmarks were automatically detected using the developed patch-based CNN algorithm. The 3D image of the face was subdivided into multiple patches, the trained CNN algorithm detected the landmarks within each patch. Partial Procrustes Analysis was applied to assess the accuracy of automated landmarking. The method allowed the measurement of the Euclidean distances between the manually detected landmarks and the corresponding ones generated by each of the two automated methods. The significance level was set at 0.05 for the differences between the measured distances.

Results:
The overall landmark localization error of Cliniface software was 3.66 ± 1.53 mm, Subalar exhibiting the largest discrepancy of more than 8 mm in comparison with the manual digitization. Stomion demonstrated the smallest error. The patch-based CNN algorithm was more accurate than Cliniface software in detecting the facial landmarks, it reached the same level of the manual precision in identifying the same points. The inaccuracy of Cliniface software in detecting the facial landmarks was significantly higher than the manual landmarking precision.

Limitations:
The study was limited to one centre, one groups of 3D images, and one operator.

Conclusions:
The patch-based CNN algorithm provided a satisfactory accuracy of automatic landmarks detection which is satisfactory for the clinical evaluation of the 3D facial images. Cliniface software is limited in its accuracy in detecting certain landmark which bounds its clinical application.
